The geomembrane surface thickness gauge is a professional instrument used to measure the thickness of textured geomembranes and related products. It is widely used in laboratory testing in civil engineering, road, water conservancy and environmental protection fields, and meets the relevant domestic and international standards.

Geomembrane Rough Surface Thickness Gauge

Model:TGHCI-2

Introduction:

This instrument is designed according to CJ/T 234-2006 standard and is mainly used to measure the thickness of textured geomembranes and related products. It also references international standards ASTM D7466/D7466M-24. The equipment is stable and reliable, suitable for export use.

Product Features:

Employs an imported digital dial gauge, which can store and view values, has one-button zeroing, and provides accurate thickness measurement.

Uses a stainless steel column, which is rust-proof, corrosion-resistant, and durable.

Uses an all-steel contact surface, with a smooth surface for easy testing.

The height is adjustable with a knob on the support, facilitating sampling and thickness measurement at different positions.

Technical Parameters:

Measuring Range: 0-127mm

Measuring Accuracy: 0.01mm

Coaxial Pressure: 0.56N + 0.054N

Dimensions: 200x150x55mm

Weight: 7.5kg
