The Triangular Wire Basket for Aggregate Soundness Test is a precision laboratory accessory designed for evaluating the soundness and durability of coarse and fine aggregates under repeated weathering conditions. It is widely used in highway engineering, construction material laboratories, universities, quality inspection agencies, and aggregate production facilities.

Triangular Wire Basket for Aggregate Soundness Test

Model:TD314WL

I. Product Overview

The basket is used together with the Aggregate Soundness Test Apparatus to simulate the deterioration of aggregates caused by repeated crystallization of sodium sulfate or magnesium sulfate. By exposing aggregate samples to cycles of solution immersion and oven drying, the test determines the resistance of aggregates to disintegration, cracking, and loss of mass caused by crystallization pressure.

Manufactured from high-quality stainless steel wire mesh, the basket offers excellent corrosion resistance, dimensional stability, and long service life, ensuring accurate and repeatable laboratory testing.

II. Available Specifications

The Triangular Wire Basket for Coarse and Fine Aggregates is available in various specifications, including basket diameters of 70 mm, 100 mm, and 150 mm, with mesh openings ranging from 0.15 mm to 2.36 mm. These baskets are primarily used for aggregate soundness testing, helping evaluate the durability of aggregates by ensuring they maintain their strength and structural stability after repeated immersion and drying cycles.

III. Test Procedure

1. Sample Preparation

Separate aggregate samples according to the required particle size and place each sample into the appropriate triangular wire basket.

The sample volume should not exceed approximately five times the basket capacity to ensure uniform exposure to the testing solution.

2. Solution Immersion

Immerse the basket completely in saturated sodium sulfate or magnesium sulfate solution maintained at 20–25°C. Keep the sample immersed for approximately 20 hours.

3. Oven Drying

Remove the basket from the solution and place it in a drying oven at 105 ± 5°C. Dry the specimen for approximately 4 hours.

4. Repeated Cycles

Repeat the immersion and drying procedure according to the applicable testing standard.

5. Washing and Final Drying

Wash the specimen thoroughly with clean water at 25–30°C to remove residual salts. Dry the sample again at 105 ± 5°C until constant mass is achieved.

6. Result Evaluation

Determine the percentage of mass loss after testing to evaluate the soundness and weathering resistance of the aggregate.

IV. Applicable Standards

The Triangular Wire Basket is designed for use with aggregate soundness tests performed according to international standards, including:

ASTM C88 — Standard Test Method for Soundness of Aggregates by Use of Sodium Sulfate or Magnesium Sulfate

AASHTO T104 — Soundness of Aggregate by Use of Sodium Sulfate or Magnesium Sulfate

EN 1367-2 — Tests for Thermal and Weathering Properties of Aggregates – Part 2

JTG E42 — Test Methods of Aggregate for Highway Engineering

V. Features

Manufactured from premium stainless steel;

Excellent corrosion resistance against sulfate solutions;

High-strength woven wire mesh construction;

Accurate mesh openings for reliable testing;

Smooth welded structure with long service life;

Easy sample loading and unloading;

Suitable for coarse and fine aggregate testing;

Stable dimensions ensure repeatable test results;

Compatible with most aggregate soundness testing apparatus;

Available in multiple sizes and mesh openings.

VI. Why Choose Our Triangular Wire Basket?

Direct manufacturer with extensive experience in laboratory testing equipment;

Precision manufacturing for consistent quality;

High-quality stainless steel materials;

Strict quality inspection before delivery;

OEM and custom manufacturing services available;

Competitive factory pricing;

Worldwide shipping and technical support
